Consew 288RB-2 High-Speed Single Needle Post Bed Needle Feed Industrial Sewing Machine

Consew 288RB-2 High-Speed Single Needle Post Bed Needle Feed Industrial Sewing Machine

288RB-2

This complete unit is powered by a high-torque Servo Motor for silent operation and stitch-by-stitch speed control.

$3,499.99
$3,499.99 Market price:
Sale Sold out
Head Only (No Table)
Delivery within 3-5 working days
View full details
  • Description
  • Features
  • Specifications
  • Application
  • Manuals & warranty

Consew 288RB-2

is a high-speed, professional-grade post bed machine designed for precision sewing of light to medium-weight materials. Its 7-inch vertical post bed provides the necessary clearance to maneuver uneven, curved, and tubular articles that a standard flatbed machine cannot handle.

Equipped with a Needle Feed mechanism, the machine ensures synchronized feeding of the needle and feed dog, preventing material "creeping" and ensuring consistent stitch lengths on delicate or multi-layered fabrics.

  • Vertical Post Bed (7"): Ideal for sewing spherical, curved, or hollow items like footwear, brassieres, and raincoats.
  • Synchronized Needle Feed: The needle moves with the material to prevent ply-shift and ensure uniform feeding on slippery or uneven surfaces.
  • Centra-Lube® System: Features a semi-automatic lubrication system and oil-fed take-up to ensure long-term durability and smooth operation at high speeds.
  • Large Vertical Axis Hook: Accommodates a large capacity bobbin, allowing for longer runs between thread changes.
  • Safety Clutch: Automatically disengages the hook in the event of a thread jam or needle strike to prevent damage to internal gears.
  • Energy-Efficient Servo Motor: Provides 90% energy savings over traditional clutch motors and allows for precise speed adjustment from very slow to full speed.
  • Max Speed: 2,400 SPM (Stitches Per Minute)
  • Stitch Length: Max 4.2 s.p.i. (6mm)
  • Post Height: 7" (178mm)
  • Clearance Under Foot: 15/64" (6mm)
  • Needle System: 135 x 17
  • Needle Bar Stroke: 1-5/16" (33mm)
  • Stitch Type: 301 Lockstitch
  • Work Surface: 2-1/8" x 2" (54mm x 51mm)
  • Footwear: Perfect for vamping, space stitching, and tipping on shoes and boots.
  • Apparel: Specialized for uneven articles such as underwear, brassieres, and raincoats.
  • Leather & Vinyl: Stitching light to medium-weight leather, canvas, and laminated materials.
  • Tubular Goods: Small bags, gloves, and curved fabric assemblies.

U.S. WARRANTY:

90 Days labor on defects in materials and workmanship.

** Head Only option does not include the table, legs, Servo Motor, and LED Lamp. No assembly or residential charges necessary.

DISCLAIMER: DUE TO THE WEIGHT AND SHIPPING METHODS USED FOR INDUSTRIAL MACHINES THEY MAY EXPERIENCE MARRING AND SCRATCHES DURING SHIPPING. THIS WILL NOT AFFECT THE OPERATION OF THE MACHINE.

JUKI DDL-8700 FAQs

What kind of needles do you use in the DDL-8700?

The needles with your JUKI are the Organ DBx1, available on our website. This machine uses size 16×257, size 8 through 20 or 16×97. The 8700 can also use standard needles, sizes 9 through 21, universal or fabric-specific needles such as knit.

Where does the machine oil go?

A pan directly underneath the machine supplies oil to the machine with a cotton wick. Lift the machine up and over to access the oil tank while on the table. You must keep the machine’s oil level consistently at the «high» mark, either by adding more oil or draining it and refilling it as needed. If the oil pump can’t get the oil into the machine, it can cause serious problems later.

What kind of oil does this machine require?

You need a specific type, like motor oil in your car, to keep this machine running. The DDL-8700 requires JUKI New Defrix Oil No.1, equivalent to ISO VG7.

What size table can I get with this machine?

Our table has legs and is 22"w x 47"l. It includes a knee and foot pedals and a left-hand drawer for accessories.

Does the DDL 8700 make buttonholes?

No. The 8700 only does straight stitching, with a horizontal bar on the right side for a reverse stitch.

THE ADVANTAGES OF A SERVO MOTOR

THE ADVANTAGES OF A SERVO MOTOR

Because of the Servo motor speed control, most users find the machine more straightforward to use. Both beginning and seasoned sewers find this feature helpful when stitching projects that don't demand high-speed stitching.

They use up to 90% less power than clutch motors

They use up to 90% less power than clutch motors

They are 1/3 lighter than clutch motors

They are 1/3 lighter than clutch motors

With a flick of the switch, you can reverse motor rotation

With a flick of the switch, you can reverse motor rotation

No parts to wear out or adjust

No parts to wear out or adjust

No matter how hard you press the foot pedal, the configured speed remains the same.

No matter how hard you press the foot pedal, the configured speed remains the same.
