Consew 104-3T Ornamental Embroidery & Tape Attaching Industrial Chainstitch Machine

Consew 104-3T Ornamental Embroidery & Tape Attaching Industrial Chainstitch Machine

104-3T

Unlike standard sewing machines, the 104-3T features a Universal Feed Movement, allowing you to steer the stitch in any direction (360 degrees) using a manual hand crank located under the table.

$3,599.95
$3,599.95 Market price:
Sale Sold out
Head Only (No Table)
Delivery within 3-5 working days
View full details
  • Description
  • Features
  • Specifications
  • Application
  • Manuals & warranty

The Consew 104-3T

is a specialized single-needle, single-thread industrial machine engineered for intricate ornamental embroidery and decorative tape attaching. Unlike standard sewing machines, the 104-3T features a Universal Feed Movement, allowing you to steer the stitch in any direction (360 degrees) using a manual hand crank located under the table. This specific model is enhanced for attaching tape to garments, bedspreads, and linens while offering the ability to switch instantly between a standard chainstitch and a plush Moss (Drop) Stitch without rethreading.

  • Universal Feed Movement: The hand-operated directional control allows for total free-hand movement, enabling you to sew complex shapes, scripts, and floral patterns in any direction.
  • Dual Stitch Capability: Equipped with a built-in device to switch between a standard Type 101 Chainstitch and a Moss (Drop) Stitch—which creates a carpet-like pile effect—instantly while the work is in the machine.
  • Precision Tape Attaching: Specifically designed for sewing decorative tapes and braids onto high-end apparel, uniforms, and home textiles.
  • Adjustable Needle Plate: Accommodates various needle sizes and nipples to work with diverse thread types, from fine silk to heavy wool and metallic threads.
  • Energy-Efficient Servo Motor: Provides a significant advantage over clutch motors with silent operation, 90% power savings, and total speed control—essential for the delicate precision of free-hand embroidery.
  • Manual Steer Control: The under-table crank handle gives the operator physical feedback and precision when navigating tight curves and intricate monogramming details.
  • Stitch Type : Single Thread Chainstitch (Type 101) & Moss Stitch
  • Max Sewing Speed : 800 Stitches Per Minute (SPM)
  • Feed System : Universal Feed (360° Manual Steer)
  • Max Stitch Length : 13/64" (5 mm)
  • Needle Bar Stroke : 9/16" (14 mm)
  • Needle System : 137x1 TR (Chain) / 137x1 SM (Moss)
  • Presser Foot Lift : 9/32" (7 mm)
  • Work Space : 10-1/4" (260 mm)

The 104-3T is a favorite among textile artists and specialty manufacturers for:

  • High-End Apparel: Attaching tape and embroidery to dresses, suits, and uniforms.
  • Home Textiles: Decorative borders on table linens, bedspreads, and curtains.
  • Personalization: Stitching names and logos onto towels and blankets for the hospitality industry.
  • Banners & Emblems: Creating textured, multi-directional designs for flags and patches.
  • Restoration: Ideal for vintage garment repair and traditional tailoring.

DOWNLOADS

U.S. WARRANTY:

90 Days labor on defects in materials and workmanship.

** Head Only option does not include the table, legs, Servo Motor, and LED Lamp. No assembly or residential charges necessary.

Disclaimer: Due to the weight and shipping methods used for industrial machines they may experience marring and scratches during shipping. This will not affect the operation of the machine.

JUKI DDL-8700 FAQs

What kind of needles do you use in the DDL-8700?

The needles with your JUKI are the Organ DBx1, available on our website. This machine uses size 16×257, size 8 through 20 or 16×97. The 8700 can also use standard needles, sizes 9 through 21, universal or fabric-specific needles such as knit.

Where does the machine oil go?

A pan directly underneath the machine supplies oil to the machine with a cotton wick. Lift the machine up and over to access the oil tank while on the table. You must keep the machine’s oil level consistently at the «high» mark, either by adding more oil or draining it and refilling it as needed. If the oil pump can’t get the oil into the machine, it can cause serious problems later.

What kind of oil does this machine require?

You need a specific type, like motor oil in your car, to keep this machine running. The DDL-8700 requires JUKI New Defrix Oil No.1, equivalent to ISO VG7.

What size table can I get with this machine?

Our table has legs and is 22"w x 47"l. It includes a knee and foot pedals and a left-hand drawer for accessories.

Does the DDL 8700 make buttonholes?

No. The 8700 only does straight stitching, with a horizontal bar on the right side for a reverse stitch.

THE ADVANTAGES OF A SERVO MOTOR

THE ADVANTAGES OF A SERVO MOTOR

Because of the Servo motor speed control, most users find the machine more straightforward to use. Both beginning and seasoned sewers find this feature helpful when stitching projects that don't demand high-speed stitching.

They use up to 90% less power than clutch motors

They use up to 90% less power than clutch motors

They are 1/3 lighter than clutch motors

They are 1/3 lighter than clutch motors

With a flick of the switch, you can reverse motor rotation

With a flick of the switch, you can reverse motor rotation

No parts to wear out or adjust

No parts to wear out or adjust

No matter how hard you press the foot pedal, the configured speed remains the same.

No matter how hard you press the foot pedal, the configured speed remains the same.
