Family Sew FS-30H Compact Portable Walking Foot Industrial Sewing Machine with Built-in Motor

Family Sew FS-30H Compact Portable Walking Foot Industrial Sewing Machine with Built-in Motor

FS-30H

Compact Portable Sewing Machine

$129.99
$129.99 Market price:
Sale Sold out
Delivery within 3-5 working days
View full details
  • Description
  • Features
  • Specifications
  • Application

Family Sew #FS-30H

is a heavy-duty portable machine engineered to bridge the gap between household sewing and full-scale industrial production. Built with a solid cast-iron frame and all-metal internal gears, it features a built-in Walking Foot (Top Feed) mechanism that prevents layers of fabric from shifting. Whether you are repairing boat canvas on-site, stitching leather belts, or hemming heavy denim, the FS-30H provides the torque and penetration power necessary for tough materials while remaining small enough to store in a closet or take on the go.

  • Marine & Outdoor: Boat covers, sail repairs, and bimini tops.
  • Leathercraft: Belts, wallets, holsters, and light-to-medium weight upholstery.
  • Home Decor: Heavy curtains, denim repairs, and canvas tote bags.
  • On-Site Repairs: Mobile upholstery repair and craft show production.
  • Integrated Walking Foot (Top Feed): The top feed dog works in tandem with the bottom feed to ensure thick, slippery, or multi-layered materials (like vinyl and upholstery) feed through without shifting.
  • Heavy-Duty All-Metal Construction: Unlike modern plastic domestic machines, the FS-30H features a cast-iron body and steel internal components for maximum durability and vibration reduction.
  • Powerful Built-in Motor: Equipped with a high-torque 110V motor and an electronic foot controller, providing the strength needed to sew through up to 4 layers of soft leather or multiple layers of heavy canvas.
  • High Presser Foot Lift: Offers significantly more clearance than standard portable machines, allowing you to easily place thick assemblies under the needle.
  • Straight and Zigzag Stitching: A versatile dual-function machine capable of both standard straight stitching and reinforced zigzag stitching (up to 5mm width).
  • Portable Design: Includes a built-in carrying handle and weighs approximately 35 lbs, making it easy to transport to craft fairs, workshops, or docks.
  • Machine Type : Portable Walking Foot (Zigzag/Straight)
  • Max. Sewing Speed : 800 stitches per minute
  • Max. Stitch Width : 5 mm
  • Max. Stitch Length : 6 mm
  • Needle System : 135 x 17 (DPx17)
  • Needle Sizes : #18 to #22
  • Thread Size : Up to Bonded Nylon #69 (B69)
  • Motor : 110V, 1.5 Amp
  • Machine Weight : Approx. 35 lbs
  • Frame Material : Cast Iron

JUKI DDL-8700 FAQs

What kind of needles do you use in the DDL-8700?

The needles with your JUKI are the Organ DBx1, available on our website. This machine uses size 16×257, size 8 through 20 or 16×97. The 8700 can also use standard needles, sizes 9 through 21, universal or fabric-specific needles such as knit.

Where does the machine oil go?

A pan directly underneath the machine supplies oil to the machine with a cotton wick. Lift the machine up and over to access the oil tank while on the table. You must keep the machine’s oil level consistently at the «high» mark, either by adding more oil or draining it and refilling it as needed. If the oil pump can’t get the oil into the machine, it can cause serious problems later.

What kind of oil does this machine require?

You need a specific type, like motor oil in your car, to keep this machine running. The DDL-8700 requires JUKI New Defrix Oil No.1, equivalent to ISO VG7.

What size table can I get with this machine?

Our table has legs and is 22"w x 47"l. It includes a knee and foot pedals and a left-hand drawer for accessories.

Does the DDL 8700 make buttonholes?

No. The 8700 only does straight stitching, with a horizontal bar on the right side for a reverse stitch.
